a:the machine adopt Taiwan TECO AC servo motor and servo speed control system during the test, the device with the similar package presses compared to control than the accuracy and quality greatly improved,stable, efficient, low noise (low speed substantially no noise) and controls much wider speed range (0.01-500mm / min),Conducive to regular speed compression test, but also conducive to the stacking test for a long time a very low speed, but also conducive to adjust the distance between the upper and lower platens when idling, saving auxiliary test time;

b:By no noise synchronous tooth type belt, zero gap precision ball screw vice "strong" assuredly composition reduction mechanism, makes the structure more concise, sprightly, the transmission efficiency is greatly improved.Under the pressure plate position host height is also greatly decreased, more convenient package easy disassemble;

c:Between the work station and lower pressure plate, the high precision load sensor and platen along evenly distributed along the circumference of the adjusting bolt installation form to measure force test. The layout is more reasonable, more effective and more accurate measurement;

d:Between the platen and the moving beam is connected with a universal spherical structure, in order to adapt to the compression process of sample partial pressure;

e:The host decorative shell host adopt Aluminum Alloy, elegant and beautiful.

f:Absorption of Shimadzu Corporation (testing machine company) advanced test machine control technology, to realize the control of constant displacement and force of the test, with arbitrary test point set and keep the function;when stacking test, according to the attenuation of packages of increasing the amount of deformation and stress test, safe and effective test result judgment, and the implementation of the right protection measures;

g:Equipped with advanced computer control and measurement system,measuring performance parameters of each package in accordance with national standards GB / T4857.3-92 and GB / T4857.4-92, Can complete the test parameters in the process of test set, test process control, data acquisition, processing, analysis and display, control and measurement precision, accurate, fast, convenient and intelligent; and the test data were statistics and processing, and output print a variety of test curve and test report.

a:The electric control circuit with reference to international standards, in line with national standards for electrical testing machine, strong anti-interference ability, to ensure the stability of the controller, the accuracy of experimental data.

b:Automatic transmission: according to the load size automatically switch to the appropriate range, to ensure the accuracy of measurement data; To achieve the automatic shifting physical zero,gain adjustment and test of force measurement, adjusting to zero, calibration and disk without any analog adjustment link, control of highly integrated circuits

c:Save conditions: control datasample test conditions can be made into modules, convenient batch test;

d:Automatic transmission speed: Mobile beam test process can be automatically pre-set change, can also manually change;

e:Automatic calibration: the system can automatically calibrate the accuracy of indication;

f:Automatic save: end of the experiment, the test data and curve automatically saved;

g:The process of implementation: testing process, measurement, display and analysis are completed by the computer;

h:Batch test: test the same parameters, can be set after a sequentially complete;

i:Test software: Chinese WINDOWS interface, menu, mouse operation.
